JediView for ARM
 |
|
Introduce The JediView Integrated Development Environment (IDE) is an application that provides a simple, versatile graphical user interface and tools for developing computer software. Using JediView, you can develop a program, library, or other executable code to run on different computer systems using different programming languages.
|
Development
Environment
· System
configuration
· Project
Manager
· Text
Editor
· Source
Graphic Browser
· Project
Builder
· Plug-in
Facility
· Flash
Memory Programming
· Shell
Windows
· CVS
· Profiler |
Features
·
IDE integrated
development environment, GCC complier-inside
· Project Manager can achieve the
projects graphics and block management
· The source program debugging support
disassembly and combination mode
· Support ThreadX, uCOS II, Linux, VxWorks, WinCE and Nucleus+ etc BSP
· Real-time debug: Single-step, full-speed run, reset, software/hardware breakpoint and
transfer etc.
· Supply necessary hardware testing tools for hardware dubugging, which can inspect if the
peripheral circuit such as CPU, RAM and Flash are OK.
· Windows for CPU register, circumjacent register, memory and stack etc, dynamic change and
real-time data check
· User-defined window, user can define the I/O of SoC and circumjacent register.
· Watch window, can add the user-defined register, memory address and variable, easy for
concentrative checking
· In-line Flash program, supports
hundreds of Flash chips
· The data in RAM or Flash can be transmitted into the computer and the data can be
downloaded into RAM or Flash.
· User can realize the software enables all the operation using the command windows and can
read and write the registers.
· Instruction-Set-Simulator function can simulate the running of ARM with software without the
emulator and target board. It’s convenient to debug and study ARM.
· Profiler can analyze the code coverage rate, time of executing module, and the rate of transfer
function. And then user can adjust the program code and improve the efficiency of execution
· CVS function makes it easy to manage
the project efficiently for developing team.
· VB Script and Shell Command can achieve debugging and testing automatically
Interface of JediView
Debugger
Real-Time-Source-Level-Debugger
Instruction-Set-Simulator
RTOS Awareness Debugger
Tool
support
STABS and ELF/DWARF1.0&2.0 and
compliant with the output format files; such as ARM ADS/SDT, EPI CC-SDT,
Greenhills MULTI2000 C/C++ cross compiler, GNU C/C++ compiler. JEDIview Studio
with embedded GNU C/C++ Compiler
Support the following operation system
Treadx,
uCOS/II, uClinux, Linux kernel
awareness debugger
JediView
Studio Hardware Protocol
JediView supports JUDI, JEDI II, JEDI,
MAJIC MAJICII, MAJICIII, MAJIC+ Ethernet In-Circuit Emulator.
Supported Processor
ARM7, ARM7DI, ARM7TDMI, ARM7TDMI-S, ARM 710T, ARM720T, ARM726FZ
ARM9, ARM9TDMI, ARM940T, ARM920T, ARM922T, ARM9E-S, ARM966E-S
MIPS32: 4kc, 4kp, 4km, 4kec & 4kem
Supported BSP debugging
Vxworks, Nucleus+, QNX, RTXC.
Ordering information
|
Model |
Products Description
|
Brand |
Remark |
|
JediView-A |
JediView standard version for ARM |
MICETEK |
|
|
JediView-AL |
JediView for Linux OS and for ARM
processors |
MICETEK |
Optional |
|
In-Circuit Emulator for ARM, loading
code with USB interface |
MICETEK |
Optional |
|
|
In-Circuit Emulator for ARM/MIPS,
loading code in a speed of 1.6Mbytes/S, Flash programming via USB
interface |
MICETEK |
Optional |
